IRTD 400 Intelligent


IRTD 400 Intelligent

of KAYE

Description

High Accurate Traceable Temperature Standard

The IRTD is a high accuracy traceable temperature standard used as part of the  Kaye Validation systems for calibrating sensors. During sensor calibration / verifications, sensors are compared against the IRTD and offsets are automatically calculated and stored.
The broad temperature range from  -195 to 420°C, enables it to be used in virtually all temperature validation applications.

The IRTD is an integral part of Kaye’s automated sensor calibration system and communicates directly with all Kaye Validation systems.. With an accuracy of +/- 0,025, the IRTD provides a 4 to 1 ratio for calibrating sensors to 0.100°C

The temperature standard can be used for confirming the accuracy of other temperature devices. For this purpose, Kaye has developed IRTDWin™ software. The IRTDWin™ software is one convenient interface screen lets you track probe stability, numerically and graphically, and confirm system accuracy.

Features

  • Temperature range -195 to 420°C
  • Accuracy over range ±0.025°C
  • Resolution 0.001°C
  • Sensor element 200 Ohm Platinum sensor

Description

High Accurate Traceable Temperature Standard

The IRTD is a high accuracy traceable temperature standard used as part of the  Kaye Validation systems for calibrating sensors. During sensor calibration / verifications, sensors are compared against the IRTD and offsets are automatically calculated and stored.
The broad temperature range from  -195 to 420°C, enables it to be used in virtually all temperature validation applications.

The IRTD is an integral part of Kaye’s automated sensor calibration system and communicates directly with all Kaye Validation systems.. With an accuracy of +/- 0,025, the IRTD provides a 4 to 1 ratio for calibrating sensors to 0.100°C

The temperature standard can be used for confirming the accuracy of other temperature devices. For this purpose, Kaye has developed IRTDWin™ software. The IRTDWin™ software is one convenient interface screen lets you track probe stability, numerically and graphically, and confirm system accuracy.

  • Temperature range -195 to 420°C
  • Accuracy over range ±0.025°C
  • Resolution 0.001°C
  • Sensor element 200 Ohm Platinum sensor
Kaye IRTD 400 Smart Temperature Standard mcscorpusa
Other features
Applications
Data Sheet
Buy online
Representation

Sheath material Inconel™ 600
Immersion depth 101.6mm (4″)
Calibration Traceable to NIST or PTB; Recommended calibration period is 1 year
Measurement rate 30 readings per second
Ambient temperature range 0 to 60°C (32 to 140°F)
Humidity Humidity 0 to 95% non-condensing
Dimensions Overall length: 603mm (23.75″); Grip: 89mm x 32mm (3.5″ x 1.25″) Sensor sheath: 457mm x 6.35mm (18″ x 0.25″)

Used for applications ranging from -196°C to 420°C and where traceability and high accuracy is required

 Coming Soon…
