Input 220 volts single phase 50 or 60 Hz.
Adjustable output from 0 to 100 volts, with display of voltage.
Direct current rectified by silicon diodes.
Ammeter with 2 ranges, 0 to 10 and 0 to 20 Amp.
Programmation managed by PLC with memorization of the polishing and etching ranges.
2 timers, polishing and etching.
Rear output to electro-polishing unit and front connector for work with special clamp-type holder.
Time delays for starting and electrolyte flow control.
Built in accordance with EC standards.
